TD45
TD45
Four-wheel-drive Tow Tractor Technical Specification
Power Type: Diesel
Rated Capacity: 48000kg
Service weight: 5800kg
Overall Length: 3840mm
Overall Width: 1670mm
Height: 2415mm
Wheelbase: 1980mm
Front Overhang: 820mm
Rear Overhang: 1040mm
Wheel Tread(F/R)： 1280/1260mm
Front Tire: 27×10.5-15-14PR
Rear Tire: 14-17.5-14PR
Towing Coupler Height(On/Under): 400/300mm
Ground Clearance: 200mm
Turning Radius: 4300mm
Travel Speed(Unloaded): 25km/h
Front Axle Load: 1900kg
Rear Axle Load: 3900kg
Max.Drawbar Pull: 45kN
Power Type: Diesel
Rated Capacity: 48000kg
Service weight: 5800kg
Overall Length: 3840mm
Overall Width: 1670mm
Height: 2415mm
Wheelbase: 1980mm
Front Overhang: 820mm
Rear Overhang: 1040mm
Wheel Tread(F/R)： 1280/1260mm
Front Tire: 27×10.5-15-14PR
Rear Tire: 14-17.5-14PR
Towing Coupler Height(On/Under): 400/300mm
Ground Clearance: 200mm
Turning Radius: 4300mm
Travel Speed(Unloaded): 25km/h
Front Axle Load: 1900kg
Rear Axle Load: 3900kg
Max.Drawbar Pull: 45kN
Quantity
TD45 ,4.5 ton diesel towing tractor,the four-wheel-drive can drive on the slipping road with High Trafficability Capacity provides a stable driving experience which improves the safety of tractor.
Plate spring with hydraulic cylinder shock absorber damping and damping provides a smoot driving configuration which improces the smooth and comfortability of the tractor.
The four-wheel-drive can drive on the slipping road with High Trafficability Capacity.
All power works on the tyres improvong the friction factor.
Plate spring with hydraulic cylinder shock absorber damping and damping provides a smoot driving configuration which improces the smooth and comfortability of the tractor.
The four-wheel-drive can drive on the slipping road with High Trafficability Capacity.
All power works on the tyres improvong the friction factor.
